M20 x 2.5 Roll Tap TiAlN Coated HSS-E 6HX Cold Forming - Europa Tool TM38272000
TM38272000
TM3827 - Roll Tap
- Cold Forming tap with oil grooves.
- For materials with at least 10% elongation.
- TiAlN coated for increased tool life.
| Thread Diameter (TDZ) | M20 |
| Pitch (TP) | 2.5 |
| Thread Length (THL) | 32mm |
| Overall Length (LF) | 140mm |
| Neck Length (LU) | 54mm |
| Shank Diameter (DCON) | 16mm |
| Drive square size (DRVS) | 12mm |
| Pre-machined Hole Diameter/Drill Size (PHD) | 18.8 |
