- The intelligent NG coils are particularly flexible and comfortable. They are adjustable. With one turn, you can set the coil to the size of the shrink fit chucks, both in length and diameter. Stop disks are no longer necessary. This means the chuck is only heated where it is intended. Even with special sizes.
Haimer Shrink Fit Machine with Cooling Facility with £4000 Tooling Voucher included (limited time only)
Shrink Fit Technology - Power Clamp
For years, HAIMER has been leading in the development of inductive shrink technology for tool holders. Many patents, mainly in the area of inductive coils, are visible proof for innovation and progress.
The patented coil technology in conjunction with the intelligent power electronics form the core of HAIMER shrink fit technology.
Perfectly coordinated assembly groups and electronic components make sure that only the clamping area of the chuck is heated in the shrinking process.
This reduces the shrinking and cooling cycle to a minimum.
HAIMER Power Clamp Economic Plus NG b/w
High performance shrink fit unit for all tools carbide and HSS from Ø 3-32 mm
- with intelligent NG coil
- Single chuck version
- with integrated contact cooling
- incl. Cooling Manager
- incl. Speed Cooler (voltage: 230V, 16A)
- incl. 1 base holder
- incl. 1 chuck support
- Power: 13 kW
- Mains voltage: 3x400-480 V, 16 A
Intelligent New Generation coil
Installation PC Profi Line
(Economic, Comfort, Preset, Air i4.0 Eco/Comfort, Preset i4.0)
Installation according to Haimer Checklist
- Connect Machine
- Functionality Check of Components
- Software Check
- Basic Training
-
£4000 tooling voucher included with all Shrink Fit Machine orders until further notice
-
The voucher , we give you a voucher to spend on spindle tooling . This is priced on list price no discount applied to the voucher .
Example .
40.440.18 -Shrink Fit Chuck Standard D-18 mm short SK40 List price 172.00 GBP , you would receive 20 off holders FOC.
